With the adoption of software-based color management systems such as ColorSync on the MAC, Integrated Color Management (ICM) on PCs, and the wide use of the International Color Consortium's (ICC) "profile" data and file formats, color as defined by internationally accepted scientific standards is now an inherent element of mainstream operating systems.
To take full advantage of this exciting new level of precision and accuracy, color data must be traceable to the Commission Internationale de l'Eclairage's (CIE) methodology and colorimetric information base. As is well known, to comply with CIE standards, color specimens must be reduced to one or five nanometer wide Hyperspectral bands of light by a spectrophotometer, a scientific instrument for measuring light intensity. Furthermore, the data that results from this spectral analysis must be transformed using CIE provided tables and formulas. When this exacting and demanding Spectral Mastering process is applied to graphical imaging, the resulting file is known as a Spectral Master and the device that employs this process is known as a Spectral Scanner
nanoPAINTER Model 5vm
5vm is the world's first desktop spectral scanner. It "paints," or illuminates images with five nanometer wide bands of light between the wavelengths of 360nm and 830nm, thereby building a Spectral Trace for each image pixel using the Visible Light portion of the Electro-Magnetic Spectrum. The colorimetric Characteristic Curve represented by the trace can be saved or immediately transformed into any of the standard CIE color spaces, including XYZ, xyY or LAB. Using the XYZ Tristimulus values, pixels can also be transformed into virtually any Device-Dependent RGB or CMYK color space.
Features As the device specification to the right shows, the system exhibits excellent spatial, photodynamic and colorimetric characteristics and repeatability. The user may select or specify a wide variety of spatial and colorimetric measurement conditions. Final output includes the raw spectral trace, any of the CIE color spaces, CIELAB encoded TIFF image files, or files encoded for the specific device-dependent color space of any printer or monitor that has been correctly profiled. An integrated Pentium-based computer acts as system host and, through a graphical user interface, automates or greatly simplifies system setup, routine measurement procedures, device calibration and communications with network-connected systems.
Benefits 5vm allows the graphical supplier to offer a new and unique high value product, spectral masters. 5vm is the first desktop imaging system to cross the significant technical threshold of complying with CIE measurement standards. This separates 5vm from all other conventional image capture systems or methods. CIE-traceable data opens new markets like image archiving and preservation. 5vm colorimetric output is also compatible with and greatly enhances the performance of all color management systems.
With the adoption of software-based color management systems such as ColorSync on the MAC, Integrated Color Management (ICM) on PCs, and the wide use of the International Color Consortium's (ICC) "profile" data and file formats, color as defined by internationally accepted scientific standards is now an inherent element of mainstream operating systems.
To take full advantage of this exciting new level of precision and accuracy, color data must be traceable to the Commission Internationale de l'Eclairage's (CIE) methodology and colorimetric information base. As is well known, to comply with CIE standards, color specimens must be reduced to one or five nanometer wide Hyperspectral bands of light by a spectrophotometer, a scientific instrument for measuring light intensity. Furthermore, the data that results from this spectral analysis must be transformed using CIE provided tables and formulas. When this exacting and demanding Spectral Mastering process is applied to graphical imaging, the resulting file is known as a Spectral Master and the device that employs this process is known as a Spectral Scanner
nanoPAINTER Model 5vm
5vm is the world's first desktop spectral scanner. It "paints," or illuminates images with five nanometer wide bands of light between the wavelengths of 360nm and 830nm, thereby building a Spectral Trace for each image pixel using the Visible Light portion of the Electro-Magnetic Spectrum. The colorimetric Characteristic Curve represented by the trace can be saved or immediately transformed into any of the standard CIE color spaces, including XYZ, xyY or LAB. Using the XYZ Tristimulus values, pixels can also be transformed into virtually any Device-Dependent RGB or CMYK color space.
Features As the device specification to the right shows, the system exhibits excellent spatial, photodynamic and colorimetric characteristics and repeatability. The user may select or specify a wide variety of spatial and colorimetric measurement conditions. Final output includes the raw spectral trace, any of the CIE color spaces, CIELAB encoded TIFF image files, or files encoded for the specific device-dependent color space of any printer or monitor that has been correctly profiled. An integrated Pentium-based computer acts as system host and, through a graphical user interface, automates or greatly simplifies system setup, routine measurement procedures, device calibration and communications with network-connected systems.
Benefits 5vm allows the graphical supplier to offer a new and unique high value product, spectral masters. 5vm is the first desktop imaging system to cross the significant technical threshold of complying with CIE measurement standards. This separates 5vm from all other conventional image capture systems or methods. CIE-traceable data opens new markets like image archiving and preservation. 5vm colorimetric output is also compatible with and greatly enhances the performance of all color management systems.
5vm SPECIFICATIONS
Spectral range . . . . . . . . . . . .
Spectral resolution . . . . . . . .
Photodynamic range . . . . . . . Photodynamic resolution . . . .
Dmax . . . . . . . . . . . . . . . . . . .
Light source . . . . . . . . . . . . . .
Spectral range . . . . . . . . . . . .
Spectral resolution . . . . . . . .
Photodynamic range . . . . . . . Photodynamic resolution . . . .
Dmax . . . . . . . . . . . . . . . . . . .
Light source . . . . . . . . . . . . . .
Illuminating/viewing system
Repeatability . . . . . . . . . . . .
(white point measure) . . . . . Spatial resolution . . . . . . . . . .
Mechanical repeatability . . . .
Pixel resolution . . . . . . . . . . .
Effective measuring area . . . .
International standards . . . . .
Trade standards . . . . . . . . . .
OS Compatibility . . . . . . . . . .
Measuring mode . . . . . . . . . .
Measuring rate . . . . . . . . . . .
Data format . . . . . . . . . . . . . .
Data presentation . . . . . . . . .
Measurement conditions . . . .
Environmental . . . . . . . . . . . .
Electrical draw . . . . . . . . . . . .
Physical . . . . . . . . . . . . . . . . .
Integrated host . . . . . . . . . . .
(white point measure) . . . . . Spatial resolution . . . . . . . . . .
Mechanical repeatability . . . .
Pixel resolution . . . . . . . . . . .
Effective measuring area . . . .
International standards . . . . .
Trade standards . . . . . . . . . .
OS Compatibility . . . . . . . . . .
Measuring mode . . . . . . . . . .
Measuring rate . . . . . . . . . . .
Data format . . . . . . . . . . . . . .
Data presentation . . . . . . . . .
Measurement conditions . . . .
Environmental . . . . . . . . . . . .
Electrical draw . . . . . . . . . . . .
Physical . . . . . . . . . . . . . . . . .
Integrated host . . . . . . . . . . .
360nm to 830nm
5nm
3.85 [log10(S/N)]
14 bits
3.9
Xenon
Transmissive 0/0
(0º illumination/0º viewing angle)
Spectral transmittance: within .1%
Colorimetric values: within DE*ab 0.1
Pixel optical measurement area:
5µm or 3µm
±.001" over area measured
up to 8,232 ppi
.92" x 1.37"
CIE: Publication 15.2
ISO: 10526, 10527
ASTM: E 308, E 1164
ANSI: CGATS.5-1993, IT8.8 1993
ICC: 1:2003-09
ColorSync 2.5, ICM 2.0, TIFF
PC, MAC, Unix, Linux
Single measurement/pixel
(optional: multiple
measurements/pixel)
209,101 pixels/second (portrait mode)
78,020 pixels/sec (landscape mode)
1,330 bits/pixel in uncompressed spectral trace mode or 24, 42 or 48 bits/pixel in tristimulus mode, or CIELAB-encoded TIFF
Spectral trace or tristimulus value
Single pixel colorimetric values:
L*a*b*, XYZ, Yxy
Image preview: sRGB
Other transforms: L*U*V*, Device RGB)
Illuminants: CIE Standard Illuminants
A, B, C, D65
also D50, D55, D75, F1 through F12
CIE Standard Observers:
CIE 2º or 10º Observers
Temperature: 60º - 80º F (15º - 26º C)
Relative humidity: 20 - 80%
110V - 60 Hz (optional: 220v - 50 Hz)
4.5 amps
540 watts
Length: 18" (457 mm)
Height: 9" (229 mm)
Width: 15" (381 mm)
Weight: 15.4 lbs (7 kg)
Pentium processor
with Windows XP & Ethernet
Specifications subject to change without notice.
