A number of links are provided to sites on the web to assist the visitor in learning more about the basic science used by Spectral Masters, Inc., or SMI. These links are not offered as a tutorial or an exhaustive listing, but rather as a starting place for the curious.
THE BASIC PHYSICAL PHENOMENA
SMI's hyperspectral technology makes reproducible measurements of specific bands of the electromagnetic spectrum, or EMS. Generally known as Light, the measured energy bands extend from the ultraviolet into the infrared and SMI relies upon phenomena of nature to make the measurements used to create images for graphical, medical and defense applications.
The four principle phenomena used by SMI are Reflection, Refraction, Diffraction and Dispersion.
SMI generally uses reflection to guide or bend the rays of light we are measuring through an optical path, from a source to a sensor. It is the natural phenomenon associated with mirrors.
Refraction takes the light rays and passes or deflects them through dissimilar material, such as air and glass, at an angle. It is the natural phenomenon associated with lenses.
Diffraction modifies the angle of light rays by passing them through narrow slits or over ruled or grooved surfaces. It is the natural phenomenon associated with diffraction gratings.
Dispersion is the process of spreading light rays into bands humans perceive as hue or color. It is the natural phenomenon associated with prisms.
SMI places special emphasis on visible, or VIS light. This is the section of the EMS that humans perceive through the sense of sight as color vision. Central to making reproducible measurements in the VIS bands is the International Illumination Commission, or CIE, the scientific body that establishes standards for measuring or numerically specifying color. SMI's imaging systems are the only ones commercially available able to make measurements consistent with CIE standards.
